Chapter 4

Multiphase Flows

4.1 Dam Break

In this tutorial, the use of custom initial conditions and two–phase flow simulations are introduced.
This is a step by step guide on how to simulate the flow of water after a dam breaks.

4.1.1 Prerequisites
• TransAT

• TransATUI

• Paraview (or Tecplot)

4.1.2 Launching TransATUI
• Double-click the TransAT icon on the Desktop.

At the top of the TransATUI window, the tabs Geo, Mesh & BCs, Input or Execute are the
different modules to set up and run a case.

4.1.3 Opening TransAT window
The first step in creating a new TransAT project is naming said project and giving it a location.

• Click to create a new project
• In the next window, navigate to the folder where the project will be saved

• To create a new project folder, click in the top right corner of the window

119
