TransAT Tutorial Manual                                            5.1. Particles in Crossflow



               Phase Properties Tab
                  In the tab Phase Properties, the physical properties of the phases of the flow are defined.
               Since the Multiphase Flow Method is turned off, only Phase 1’s fluid properties should be
               available in the phase tree.
                   • In the phase tree, click Phase 1 and fill in the corresponding fields with the following values

                     Density : 1.0
                     Viscosity : 1.70 e−05
                     Conductivity : 0.026
                     Thermal Expansion : 0.0
                     Heat Capacity : 1005.0





























                                                Figure 5.4: Phase properties


























                c
Ascomp AG Switzerland                    196                                  Version 5.7
