TransAT Tutorial Manual 4.5. Spillway

X Position : 12.3 [m]
Y Position : 2.05 [m]
Z Position : 2.335 [m]

• Click . This will move the Spillway outside the current mesh.

You will need to update the mesh, as the Spillway will have moved out of its bounds. To do so

• Go to the Mesh & BCs Tab

• Change the lower bounds of the mesh to values near zero
• The next section will describe exact settings for the mesh

4.5.7 Mesh & BCs Tab

In the Mesh & BCs tab, the domain is defined, the mesh created and the boundary conditions
set.
• Click Mesh & BCs at the top of the TransATUI.

c
Ascomp AG Switzerland 173 Version 5.7
