TransAT Tutorial Manual                                           1.2. Backward Facing Step




                     V−Velocity
                         Method : Constant
                         Value : 0

                     W−Velocity
                         Method : Constant
                         Value : 0

                     Pressure
                         Method : Constant
                         Value : 0




               Output Management
                  The parameters of the simulation outputs are defined in the Output Management tab.

                   • Click Output Management on the left-hand side of the TransATUI


                   • Set the Output File Format and Frequency of output files from Iteration / timestep
                     number as follows

                     Output F i l e Format : Paraview
                     Frequency of output f i l e s : 100




                   • Click                  to select the variables for which data is to be saved

                   • Activate the following variables in the Output Variables window then click  to save the
                     settings and close the window

                     Primary v a r i a b l e s :
                       Pressure     : ON
                       U−Velocity : ON
                       V−Velocity : ON
                       W−Velocity : ON




               1.2.7    Execute Tab

                   • Click Execute at the top of the TransATUI.


               This tab is where the simulation is started and controlled.






                c
Ascomp AG Switzerland                    22                                   Version 5.7
