TransAT Tutorial Manual 4.4. Film Boiling
Figure 4.19: Phase Change Properties
Phase Properties
• Click Phase Properties
Since the Level-Set method is used, the number of phases is set to 2. The properties to be set for
both phases are given below.
• Select the phase to be edited by clicking the corresponding phase in the phase tree and
enter its properties
Phase 1
Density : 5.0
Viscosity : 0.005
Thermal Conductivity : 1.0
Heat Capacity : 200.0
Phase 2
Density : 200.0
Viscosity : 0.1
Thermal Conductivity : 40.0
Heat Capacity : 400.0
c
Ascomp AG Switzerland 163 Version 5.7
