TransAT Tutorial Manual 7.3. Oilspill

Boundary : XMin
XMin 0: outflow

Boundary : YMax
YMax 0: outflow

Boundary : YMin 0 ( where the subBC i s )
YMin 0: wall
YMin 0 1 (SubBC ) : inflow
Boundary : Zmax
ZMax 0: symmetry

Boundary : ZMin
Zmin 0: symmetry

The mesh is now ready.

• Click Files in the top left corner then select Save

• Click in the pop-up window when asked to overwrite the project setup to save the
settings.
