TransAT Tutorial Manual 10.2. Natural Convection in a Square Cavity at Ra = 10 6
Figure 10.10: Simulation Parameters
• Click File − > Open.
• Navigate to your project folder.
• Go to the RESULT folder and choose xy-naturalconvection...vtm. Click OK
• Click in the Properties Panel, on the bottom left.
• Select variable T from the variables drop-down list to show the temperature distribution in
the domain.
