TransAT Tutorial Manual            2.1. Block Mesh Refinement: Flow over Cylinder (Re=150)





































                                              Figure 2.1: Boundary conditions


               2.1.5.2   Input Tab

                   • Click Input at the top of the TransATUI to set up the simulation parameters

               Physical Models


                   • Select the Physical models tab

                   • Select the following equations in the Basic Equations section
                     Basic Equations :
                        Pressure       : ON
                        U Velocity     : ON
                        V Velocity     : ON
                        W Velocity     : OFF
                        Temperature    : OFF
                        Concentration : OFF



                   • Activate Reference Properties and click      to the right.






                c
