TransAT Tutorial Manual            2.1. Block Mesh Refinement: Flow over Cylinder (Re=150)



                   • Set the following parameters in the reference properties window then click  to save the
                     settings
                       Reference Velocity : 0.015
                       Reference Length : 1.0



               Phase Properties
                  In the Phase Properties tab the phases of the flow are defined.

                   • Click Phase Properties on the left-hand side of the TransATUI
                   • Select Phase 1

                   • Define the fluid of Phase 1 by directly entering its physical properties’ values as follows.

                     Phase 1
                       Density   : 1.0
                       Viscosity : 0.0001 ( constant )
























                                                Figure 2.2: Phase Properties
