TransAT Tutorial Manual                                                5.2. particleseparator



                   • Select Y Min in the drop-down list.
                   • Highlight YMIN 0 in the surface tree.

                   • Check outflowbottom in the list of boundary conditions.

                   • Click

               YMIN 0 in the surface tree takes the color of the boundary condition after being assigned.

                   • Select Y Max in the drop-down list at the top of the BCs tab.

                   • Highlight YMAX 0 in the surface tree.

                   • Check outflowtop in the list of boundary conditions.

                   • Click

               YMAX 0 in the surface tree takes the color of the boundary condition after being assigned.

               The mesh is now ready.

                   • Click Files then select Save to save the settings
