TransAT Tutorial Manual 5.2. particleseparator

• Set the following parameters in the different tabs of the Lagrangian Particle Tracking win-
dow then click to save the settings
Properties tab
P a r t i c l e Density : 4000 [ kg/mˆ3]
Computational Ratio : 1000
Volume Fraction : 0.0
Number of p a r t i c l e s i z e bins : 4
Diameters [m] Min : 50e−6
Max: 200e−6
Size PDF Function : Gaussian
Physics tab
Momentum Coupling : Two−way
Two−way Coupling : Gaussian
Strong F−P Coupling : ON
Forces tab
Drag Force : ON
Buoyancy Force : ON
Convective Heat Transfer : ON

Boundary Conditions tab
P a r t i c l e Inflow Type : Per Boundary

Phase Properties

• Click Phase Properties on the left-hand side of the TransATUI

• Select the Phase Properties tab

• Select Phase 1 in the surface tree and enter the following fluid properties
Phase 1 ( Water )
General p r o p e r t i e s :
Density : 997.78
Viscosity : 0.0009772
