TransAT Tutorial Manual                                 10.3. Droplet Impact on a Flat Plate



               Phase Properties
                  The Phase Properties tab is used to define the phases of the flow. Phase properties can be
               imported from the material library or defined by directly modifying the corresponding fields.

                   • Click Phase Properties on the left-hand side of the TransATUI

                   • Set the following physical properties for Phase 1 and Phase 2 as in Figure 10.14.
                     Phase 1
                        Density :                1
                        Viscosity :              1.511 e−05

                     Phase 2
                        Density :                1000
                        Viscosity :              0.001
































                                               Figure 10.14: Phase properties



















                c
Ascomp AG Switzerland                    421                                  Version 5.7
